Gigabyte B760M DS3H AX DDR4 — Wi-Fi 6E and two PCIe 4.0 M.2 slots for an Intel build that keeps its DDR4

An Ultra Durable Micro-ATX board on Intel's B760 chipset for 12th, 13th and 14th Gen Intel Core processors on Socket LGA1700. It is the DDR4 version of the B760M DS3H AX, so it takes the memory you already own: four DDR4 slots up to 128 GB at up to 3200 MT/s. Around that sit two M.2 PCIe 4.0 x4 sockets, a PCIe 4.0 x16 graphics slot, Wi-Fi 6E with Bluetooth, 2.5 Gb/s Realtek LAN and a 10 Gb/s USB Type-C port on the back.

Gigabyte B760M DS3H AX DDR4 Ultra Durable retail box beside the Micro-ATX motherboard with its Wi-Fi antenna connectors
SocketIntel LGA1700
ChipsetIntel B760
MemoryDDR4 · 4 DIMM
Form FactorMicro-ATX
WirelessWi-Fi 6E + BT
01

Board Map

Pictured with the rear I/O along the top edge
Gigabyte B760M DS3H AX DDR4 top-down layout showing the LGA1700 socket, four DDR4 slots, heatsink-covered M.2 slot, PCIe x16 slot, chipset heatsink and rear I/O edge
1

LGA1700 socket — right of centre

Silkscreened Socket 1700 and B760M DS3H AX DDR4. It takes 12th, 13th and 14th Gen Intel Core processors as well as Pentium Gold and Celeron, and uses the standard LGA1700 cooler mounting.

2

4 × DDR4 DIMM slots — below the socket

Silkscreened DDR4_A1, DDR4_A2, DDR4_B1 and DDR4_B2. Dual-channel DDR4 at 2133 to 3200 MT/s, up to 128 GB with four 32 GB modules, and XMP profiles are supported.

3

VRM heatsink — along the I/O edge

A finned heatsink covers the power stage that runs along the rear I/O. The 8-pin ATX 12V CPU power connector sits at the top-right corner, right next to it.

4

M2A_CPU under its own heatsink — beside the x16 slot

The first M.2 PCIe 4.0 x4 socket is wired straight to the processor and sits under a full-length heatsink between the graphics slot and the socket. This is the natural place for the boot drive.

5

PCIe 4.0 x16 slot — PCIEX16

The long slot runs at PCIe 4.0 x16 from the CPU. Next to it are PCIEX1_1 and PCIEX1_2, two PCIe 3.0 x1 slots from the chipset for a capture, sound or network card.

6

M2P_SB — lower left

The second M.2 PCIe 4.0 x4 socket hangs off the B760 chipset. It takes another 2280 NVMe drive, so you get two Gen4 SSDs without giving up a SATA port.

7

Chipset heatsink, SATA and power — bottom edge

The large finned block in the lower half cools the B760 chipset. Along the bottom edge are the four SATA 6 Gb/s ports, the front USB 3.2 header and the 24-pin ATX main power connector.

8

Header row — left edge

Front-panel audio, D_LED (addressable RGB) and LED_C (RGB) strip headers, the QFLASH_PLUS button, F_USB1 / F_USB2, SPI_TPM, SYS_FAN3, CLR_CMOS and F_PANEL. The board is also marked ErP Ready.

02

Power, Cooling & Control

What feeds the socket, and what keeps the board in check
Gigabyte B760M DS3H AX DDR4 angled view of the VRM heatsink beside the socket, the M.2 heatsink above the PCIe x16 slot and the gold SMA antenna connectors on the I/O edge
24-pin ATXMain board power
8-pin ATX 12VCPU power
1 CPU + 3 system fansFan headers with speed control
ARGB + RGBD_LED and LED_C strip headers

Three heatsinks where they count

As the angled shot shows, finned heatsinks sit on the VRM beside the socket, over the M2A_CPU Gen4 SSD and on the B760 chipset. Those are the three places a Micro-ATX board in a compact case heats up first.

Hardware monitor and fan control

The iTE controller reads voltage, temperatures and fan speeds, warns on a fan failure, and can read the flow rate of a water-cooling loop. Fan speed control runs across the CPU fan header and the three system fan headers, depending on the fans you install.

Q-Flash Plus

A dedicated QFLASH_PLUS button on the board edge flashes a new BIOS from a USB stick. That matters on a 2023-era board: if the BIOS it shipped with predates the CPU you are installing, you can update it first.

GIGABYTE Control Center

GIGABYTE's Windows utility hub for the board, alongside a 128 Mbit AMI UEFI BIOS with Q-Flash built in for updates from inside the BIOS itself.

03

Lane Map

Interface speed rating & capability relative to modern motherboard standards
PCIe 4.0 x16Graphics card slot · CPU lanes
PCIe 4.0 x16
M.2 PCIe 4.0 x4 · M2A_CPUNVMe boot drive, wired to the CPU
PCIe 4.0 x4
M.2 PCIe 4.0 x4 · M2P_SBSecond NVMe drive, via the chipset
PCIe 4.0 x4
2.5GbE LANRealtek wired network
2.5 Gb/s
Wi-Fi 6E2.4 / 5 / 6 GHz bands + Bluetooth
Wi-Fi 6E
USB 3.2 Gen 2 Type-CRear Type-C port
10 Gb/s
USB 3.2 Gen 1 × 53 rear + 2 via the front header
5 Gb/s
SATA 6 Gb/s × 4HDDs and 2.5-inch SSDs · RAID 0/1/5/10
6 Gb/s each
PCIe 3.0 x1 × 2Capture, sound or network card
PCIe 3.0 x1
04

Rear I/O Bay

Exactly what appears on the back of your case
Gigabyte B760M DS3H AX DDR4 rear I/O panel with PS/2, two USB 2.0, two SMA antenna connectors, HDMI, two DisplayPorts, USB Type-C, three USB 3.2 Gen 1, 2.5GbE LAN and three audio jacks
Port inventoryEverything on the panel, counted — not in physical order
1×USB Type-CUSB 3.2 Gen 2 · 10 Gb/s
3×USB 3.2 Gen 1 Type-A5 Gb/s · the blue ports
2×USB 2.0 Type-AKeyboard, mouse, dongles
1×HDMIHDMI 2.1 · up to 4096×2160@60Hz
2×DisplayPortDP 1.2 · up to 4096×2304@60Hz
2×SMA antennaFor the bundled Wi-Fi 6E antenna
1×RJ-45 LANRealtek 2.5GbE
1×PS/2Keyboard or mouse
3×Audio jacksRealtek HD audio, up to 7.1-channel
05

Will It Fit Your Build?

Check these before you add to cart
✓

Processor

12th, 13th and 14th Gen Intel Core, Pentium Gold and Celeron on Socket LGA1700.

✓

Memory

DDR4 only — 4 slots, dual channel, 2133 to 3200 MT/s, up to 128 GB. Your existing DDR4 kit carries over; DDR5 modules will not fit.

✓

Storage

Two M.2 PCIe 4.0 x4 sockets (one from the CPU, one from the chipset) plus 4 × SATA 6 Gb/s with RAID 0/1/5/10.

✓

Networking

Wi-Fi 6E with Bluetooth and the antenna in the box, plus 2.5GbE wired LAN.

✓

Case

Micro-ATX, 24.4 × 24.4 cm — fits any Micro-ATX, Mid-Tower or Full-Tower ATX chassis.

✓

Cooler

Standard LGA1700 mounting, so the Intel stock cooler and LGA1700-compatible towers and AIOs fit.

!

Graphics: check your CPU

The HDMI and DisplayPort outputs only work with a CPU that has integrated graphics. Intel F-series chips (for example a Core i5-12400F) have none, so with those you must fit a graphics card.

!

No CPU multiplier overclocking

The B760 chipset does not unlock CPU ratio overclocking, even on K-series chips. Memory XMP profiles are supported.

06

Full Specification Sheet

Gigabyte B760M DS3H AX DDR4 (rev. 1.x)
CPU Socket Intel LGA1700
CPU Support 14th, 13th and 12th Gen Intel Core · Pentium Gold · Celeron
Chipset Intel B760 Express
Form Factor Micro-ATX, 24.4 × 24.4 cm
Memory Slots 4 × DDR4 DIMM, dual channel
Memory Speed DDR4 3200 / 3000 / 2933 / 2666 / 2400 / 2133 MT/s · XMP supported
Max Memory 128 GB (32 GB per DIMM)
Graphics Slot 1 × PCIe 4.0 x16 (CPU) · 2 × PCIe 3.0 x1 (chipset)
M.2 Storage 2 × M.2 2280 PCIe 4.0 x4/x2 — M2A_CPU (CPU) and M2P_SB (chipset)
SATA Ports 4 × SATA 6 Gb/s · RAID 0, 1, 5, 10
Rear Video Out 1 × HDMI (HDMI 2.1, up to 4096×2160@60Hz, HDCP 2.3) · 2 × DisplayPort 1.2 (up to 4096×2304@60Hz) · up to three displays · needs a CPU with integrated graphics
Rear USB 1 × USB Type-C (USB 3.2 Gen 2) · 3 × USB 3.2 Gen 1 · 2 × USB 2.0
Internal USB 1 × USB 3.2 Gen 1 header (2 ports) · 2 × USB 2.0 headers (4 ports)
LAN Realtek 2.5GbE
Wireless Wi-Fi 6E (2.4 / 5 / 6 GHz) with Bluetooth 5.2 or 5.3; the module depends on the PCB revision · 2 × SMA antenna connectors
Audio Realtek HD audio codec · 2 / 4 / 5.1 / 7.1-channel · S/PDIF Out header
Fan & RGB Headers 1 × CPU fan · 3 × system fan · 1 × addressable LED strip · 1 × RGB LED strip
Other Internal 24-pin ATX · 8-pin ATX 12V · TPM header · front panel and audio · Q-Flash Plus button · Clear CMOS jumper
Rear Legacy 1 × PS/2 keyboard/mouse port
BIOS 128 Mbit flash · AMI UEFI · Q-Flash, Q-Flash Plus
Software GIGABYTE Control Center (GCC)
Operating System Windows 11 / Windows 10, 64-bit
In the Box Motherboard · user's manual · I/O shield · 2 SATA cables · Wi-Fi antenna · M.2 screw
07

Build Q&A

The questions builders actually ask about this board
What is the difference between this and the regular B760M DS3H AX?+
Memory. This is the DDR4 version: four DDR4 slots up to 128 GB at up to 3200 MT/s. The regular B760M DS3H AX takes DDR5 instead. Wi-Fi 6E, 2.5GbE, the two Gen4 M.2 sockets and the PCIe 4.0 x16 slot are the same on both.
Will a 14th Gen Core processor work straight away?+
14th Gen is supported, but the silkscreen on this board still reads 13th Gen, because the board launched before 14th Gen did. If the BIOS on your unit is older than your CPU, update it first. Q-Flash Plus does that from a USB stick using the dedicated button. You can also ask us to flash it when you buy the CPU with the board.
Can I run two NVMe SSDs at Gen4 speed?+
Yes. M2A_CPU is wired to the processor and M2P_SB to the B760 chipset, and both are M.2 2280 PCIe 4.0 x4. M2A_CPU has its own heatsink, which makes it the natural slot for the boot drive.
Do the HDMI and DisplayPort outputs work with my CPU?+
Only if the CPU has integrated graphics. Intel F-series chips such as the Core i5-12400F or i5-13400F have none, so they need a graphics card. With a non-F chip you can drive up to three displays from HDMI 2.1 and the two DisplayPorts.
What Wi-Fi and Bluetooth does it have?+
Wi-Fi 6E across the 2.4, 5 and 6 GHz bands, plus Bluetooth. GIGABYTE has fitted different Wi-Fi 6E modules across PCB revisions, which is why Bluetooth is 5.2 on rev. 1.0 and 5.3 on later revisions. The antenna is in the box and screws onto the two SMA connectors.
Can I overclock on B760?+
Not the CPU multiplier. B760 does not unlock CPU ratio overclocking, even with a K-series processor. Memory XMP profiles are supported, so a DDR4-3200 kit runs at its rated speed.
How many fans and RGB strips can I connect?+
One CPU fan header plus three system fan headers, with fan speed control. For lighting there is one addressable RGB header (D_LED) and one standard RGB header (LED_C).
Does it have a USB Type-C port?+
Yes. There is one rear USB Type-C at USB 3.2 Gen 2 (10 Gb/s), alongside three blue USB 3.2 Gen 1 ports and two USB 2.0 ports. A front USB 3.2 Gen 1 header adds two more 5 Gb/s ports on the case.
