Lian Li EDGE Gold EG0850G 850W 80 PLUS Gold · ATX 3.1 · L-Shape Fully Modular
The EDGE Gold 850W turns its modular connectors outward in an L-shape, built for the vertical PSU mount in dual-chamber cases like the LIAN LI O11 series, and it ships with longer braided-texture cables that also reach in regular towers. It is 80 PLUS Gold and Cybenetics Gold certified (up to 90.71% efficiency), meets ATX 3.1 / PCIe 5.1 with a dual-colour 12V-2x6 rated 450W, uses German EPCOS or equivalent Japanese capacitors, and carries a 10-year warranty. The 850W version comes without the EDGE USB/PWM hub.
Gaming Rigs with a 12V-2x6 GPU
A native 12V-2x6 cable rated 450W plus two 6+2-pin PCIe cables and a daisy-chained 6+2 lead cover modern graphics cards, with 849W available on the +12V rail.
Dual-Chamber Showcase Builds
The outward-facing connector bay sits toward the cable chamber when the PSU is mounted vertically, and pre-installed cable combs on the 24-pin, CPU and GPU cables keep runs straight.
Power Architecture & Thermal Highlights
L-Shape Connector Bay with Magnetic Dust Filter
The photo shows the EG0850G's defining shape: the modular sockets sit on an outward step on the left, while the 120 mm FDB fan breathes through the mesh top, covered by a removable magnetic dust filter (66.9% porosity). The fan has a zero-RPM mode at low load.
Recommended Component Synergy
Processors (CPUs)
Continuous clean power delivery for multi-threaded CPUs under maximum boost.
Graphics Cards (GPUs)
Native 12V-2x6 single-cable feeding RTX 40 & 50 series graphics cards.
Motherboards
Dual EPS 8-pin connectors to feed reinforced VRM power stages.
PC Cases
Compact chassis length ensuring generous cable management clearance.
Build Your Dream Custom PC with Certified AHW Engineers
Select 100% compatible components and let our engineers assemble, cable-manage, and stress-test your rig.
Comprehensive Hardware Specifications
| Model | LIAN LI EDGE Gold 850 · EG0850G (Black) |
| Max DC Output | 850W |
| Combined +12V / +3.3V & +5V | 849W / 120W |
| Certification | 80 PLUS Gold · Cybenetics Gold · PPLP Gold |
| Peak Efficiency | 90.71% |
| Form Factor | ATX 3.1, PCIe 5.1, fully modular, L-shape |
| Dimensions (D × W × H) | 182 × 86 × 150 mm |
| Input | 100–240 Vac, 10–5 A, 50–60 Hz · Active PFC (PF > 0.90) |
| 12V-2x6 | 1 × dual-colour 12V-2x6 rated 450W (650 mm) |
| PCIe 6+2-pin | 2 × 6+2-pin (650 mm) + 1 × 6+2-pin daisy-chain (650 + 100 mm) |
| CPU | 1 × 8-pin + 1 × 4+4-pin (750 mm) |
| Motherboard | 1 × 24/20-pin (620 mm) |
| SATA / Peripheral | 3 SATA cables · 1 × 4-pin peripheral cable (4 connectors) |
| Fan | 120 mm FDB, zero-RPM mode at low load |
| Capacitors | German EPCOS or equivalent Japanese |
| Protections | OCP / OVP / OTP / OPP / SCP / UVP |
| USB / PWM Hub | Not included on the 850W model |
| Warranty | 10 years (Lian Li) |
